Ultra Drive 3D™

Our Ultra Drive 3D™ helps you save up to 50% on base excavation and fill up to 50% in poor base soil during your hardscape projects. SRW Products paver base replacement is the strongest three dimensional driveway grid on the market and is best suited for paver, asphalt, and concrete driveways.

Contact Us
View Tech Sheets
Looking to Buy?

If you are a contractor looking to try one of our products, click here for a dealer in your area, or click here to connect with your local sales rep for a demo.

If you are a dealer looking for an in-store demo or to bring a product in, click here to find your local sales rep.

If you are a homeowner, click here to find a dealer in your area.

Contact Us

Ultra Drive 3D™ Instructions

    1. Excavation

      1. Total excavation depth will be determined by several factors including paved surface thickness, bedding sand layer (paver applications), total aggregate base thickness. Simply add all of the various elements to reach the total excavation depth.
      2. Excavate the area of the paved surface down to the desired depth.
      3. Take care to properly slope and grade the native soil while excavating to achieve intended water drainage.

    2. Preparation

      1. Compact the excavated area using a plate tamper or a ride on drum roller.
        1. Additional compaction can be achieved if using a ride-on drum roller with a vibrating front drum.
        2. Hydrate the area if necessary, to achieve maximum compaction.
      2. Using SRW Products SS5 Woven Separation Fabric, roll out the geotextile over the entire area of the project overlapping 18”-24” at the seams. Allow for excess material (12”) on each side of the final paved surface.
      3. Pull the fabric taught and secure using staples.
      4. Product Tip: Installing a separation fabric is critical to the longevity of a proper sub-base system. Separation fabric prevents the migration of material between the Aggregate base and the native soil, which can directly lead to premature failure of the base support under any paved surface.
      5. Spread out the desired aggregate base material to a depth of 1”, taking great caution not to drive equipment directly on the SS5 fabric.

    3. Installation

      1. Unroll the Ultra Drive 3D™ in the same direction as the driveway/direction of traffic (start at the garage/apron and unroll to the street).
        1. Overlap the Ultra Drive 3D™ grid 18” at seams.
      2. Pull the grid taught, and secure with staples if necessary to keep it flat.
      3. Spread out a 2” layer of base material over the Ultra Drive 3D™, again taking great caution not to drive equipment on the grid.
      4. Compact the base material using a plate compactor or ride-on drum roller. Compact multiple times, in opposing directions, until the base material is as compacted as possible.
      5. Repeat the previous two steps (3c and 3d) until full base thickness is achieved. Make certain the base is compacted every 2” lift in order to ensure complete interlock with the grid.
      6. Install the paved surface according to manufacturer recommendations.
